Cisco SG500-28P Administration Guide

Access Control
IPv6-Based ACLs
Cisco 500 Series Stackable Managed Switch Administration Guide Release 1.3 470
24
NOTE ACLs are also used as the building elements of flow definitions for per-flow QoS
handling (see QoS Advanced Mode).
Defining an IPv6-based ACL
To define an IPv6-based ACL:
STEP 1 Click Access Control > IPv6-Based ACL.
This window contains the list of defined ACLs and their contents
STEP 2 Click Add.
STEP 3 Enter the name of a new ACL in the ACL Name field. The names are
case-sensitive.
STEP 4 Click Apply. The IPv6-based ACL is saved to the Running Configuration file.
Adding Rules (ACEs) for an IPv6-Based ACL
STEP 1 Click Access Control > IPv6-Based ACE.
This window contains the ACE (rules) for a specified ACL (group of rules).
STEP 2 Select an ACL, and click Go. All currently-defined IP ACEs for the selected ACL are
displayed.
STEP 3 Click Add.
STEP 4 Enter the parameters.
• ACL Name—Displays the name of the ACL to which an ACE is being added.
• Priority—Enter the priority. ACEs with higher priority are processed first.
• Action—Select the action assigned to the packet matching the ACE. The
options are as follows:
- Permit—Forward packets that meet the ACE criteria.
- Deny—Drop packets that meet the ACE criteria.
- Shutdown—Drop packets that meet the ACE criteria, and disable the
port to which the packets were addressed. Ports are reactivated from the
Port Management page.

Cisco SG500-28P Specifications

General

Switching Capacity	56 Gbps
Forwarding Rate	41.67 Mpps
Flash Memory	32 MB
Operating Humidity	10% to 90% non-condensing
PoE	Yes
Layer	Layer 2 and Layer 3
Stackable	Yes
Power Supply	Internal
Management	Web-based GUI, CLI, SNMP
Jumbo Frame Support	Yes
VLANs	4096 VLANs
MAC Address Table Size	16K entries
Dimensions	440 x 44 x 350 mm
Operating Temperature	0°C to 45°C
Ports	28 (24 x 10/100/1000 PoE+ ports, 4 x 10/100/1000/SFP combo ports)
