Cisco SG500-28P Administration Guide

Quality of Service
Configuring QoS - General
Cisco 500 Series Stackable Managed Switch Administration Guide Release 1.3 486
25
Queue
667 54321
DSCP
61 53 45 37 29 21 13 5
Queue
667 54321
DSCP
60 52 44 36 28 20 12 4
Queue
667 54321
DSCP
59 51 43 35 27 19 11 3
Queue
667 54321
DSCP
58 50 42 34 26 18 10 2
Queue
667 54321
DSCP
57 49 41 33 25 17 9 1
Queue
667 54321
DSCP
56 48 40 32 24 16 8 0
Queue
666 76611
Table 6 DSCP to Queue Default Mapping – 8 Queues System (8 is highest)
DSCP
63 55 47 39 31 23 15 7
Queue
7 78 65431
DSCP
62 54 46 38 30 22 14 6
Queue
7 78 65431
DSCP
61 53 45 37 29 21 13 5
Queue
7 78 65431
DSCP
60 52 44 36 28 20 12 4
Queue
7 78 65431
Table 5 DSCP to Queue Default Mapping – 8 Queues System (7 is highest
and 8 is used for stack control purposes)

Cisco SG500-28P Specifications

General

Switching Capacity	56 Gbps
Forwarding Rate	41.67 Mpps
Flash Memory	32 MB
Operating Humidity	10% to 90% non-condensing
PoE	Yes
Layer	Layer 2 and Layer 3
Stackable	Yes
Power Supply	Internal
Management	Web-based GUI, CLI, SNMP
Jumbo Frame Support	Yes
VLANs	4096 VLANs
MAC Address Table Size	16K entries
Dimensions	440 x 44 x 350 mm
Operating Temperature	0°C to 45°C
Ports	28 (24 x 10/100/1000 PoE+ ports, 4 x 10/100/1000/SFP combo ports)
