Port Mirroring
SPS208G/SPS224G4/SPS2024 Service Provider Switches User Guide 250
13
The Port Mirroring Parameters contains the following fields:
• Source Port — Defines the port from which traffic is analyzed and copied.
The possible values are:
-
Unit No.
— Indicates the stacking member that contains the port being
copied.
-
Port
— Indicates the port being copied.
• Typ e — Indicates the port mode configuration for port mirroring. The
possible field values are:
-
RxOnly
— Defines the port mirroring on received packets only. This is
the default value.
-
Tx On l y
— Defines the port mirroring on transmitted packets only.
-
Both
— Defines the port mirroring on both received and transmitted
packets.
• Ta r g e t P o r t — Defines the port to which traffic is mirrored. A single target
port can be specified. The possible values are:
-
Unit No.
— Indicates the stacking member that contains the port to
which traffic is mirrored.
-
Port
— Indicates the port to which traffic is mirrored.
STEP 2 Define the relevant fields.
STEP 3 Click Add to List. The new port mirroring entry is displayed in the Port Mirroring
Table at the bottom of the screen.
The Add to List button adds the port mirroring entry to the Port Mirroring Table.
To modify a port mirroring entry:
STEP 1 Select the entry in the Port Mirroring Table.
STEP 2 Define the relevant fields.
STEP 3 Click Update. The port mirroring entry is updated in the Port Mirroring Table.
STEP 4 Click Save Settings. The port mirroring configuration is updated in the device.
