VLAN Management
Ports to VLAN
SPS208G/SPS224G4/SPS2024 Service Provider Switches User Guide 57
4
Figure 20 Show All Ports Table
The
Show All Ports Table
contains the following columns:
• Port — Lists the Ethernet ports, Gigabit ports, and LAGs.
• Mode — Indicates the possible port mode: Access, Trunk, General, or
Customer.
• PVID — Indicates the port default VLAN ID.
• VLANs — Indicates the VLAN for which the port membership is configured.
STEP 3 Select the relevant configuration options for the interfaces that are included in the
VLAN.
STEP 4 Click Save Settings to save the VLAN membership configuration. The device is
updated.
