VLAN Management
VLAN to Port
SPS208G/SPS224G4/SPS2024 Service Provider Switches User Guide 62
4
-
Trunk
— Indicates the port belongs to VLANs in which all VLANs are
tagged, except for one VLAN that is untagged.
-
Customer
— The port belongs to a VLAN in which all ports are
untagged.
• Join VLAN — Defines the VLANs to which the interface is joined. Pressing
the Join VLAN button displays the
Join VLAN to Port
Screen
. Select the
VLAN to which to add the port, select the VLANs to be tagged or untagged
and click Add. To remove the VLAN allocation to the port, select the VLAN
already assigned to the port and click Remove.
• VLANs — Specifies the VLAN in which the port is a member.
• LAG — if the port is a member of a LAG, the LAG number is displayed. A
member of a LAG cannot be configured to a VLAN, but that same LAG can
be configured to a VLAN.
STEP 2 Click Show All to display a list showing all the items through which you can scroll.
Figure 22 Show All Ports Table
