Cisco VG204 Software Configuration Guide

4-7
Cisco VG202 and Cisco VG204 Voice Gateways Software Configuration Guide
OL-16191-01
Chapter 4 Configuring Voice
Configuring the Voice Interface for Cisco CallManager
Configuring the Voice Interface for Cisco CallManager
To configure voice ports to a Cisco Unified Communications Manager server and set various
parameters—including IP address, port number, and version number, use the following commands.
Note The following steps are required only when the voice interface is configured manually and not through
auto-configuration.
SUMMARY STEPS
1. enable
2. configure terminal
3. stcapp ccm-group group-id
4. stcapp
5. stcapp feature access-code
6. stcapp feature speed-dial
7. voice-port slot-number/port
8. timeouts initial seconds
9. timeouts interdigit seconds
10. timeouts ringing seconds infinity
11. voice-port slot-number/port
12. ccm-manager fax protocol [protocol cisco]
13. ccm-manager config [server] ip-address name seconds
14. ccm-manager sccp local interface-type interface-number
15. ccm-manager sccp
16. sccp local interface-type interface-number port port-type
Step 9
ccm-manager config server tftp_ip_address
Example:
VG(config)# ccm-manager config server tftp
9.13.38.245
Specifies the TFTP server from which the voice gateway
downloads Cisco CallManager XML configuration files
and enables the download of the configuration port
port-number.
Step 10
ccm-manager sccp
Example:
VG(config)# ccm-manager C
Enables Cisco CallManager autoconfiguration of the
Cisco IOS gateway.
Step 11
exit
Example:
VG(config-line)# exit
Exits to global configuration mode.
Command or Action Purpose

Cisco VG204 Specifications

General

Number of FXS Ports	4
Voice Codecs	G.711, G.729, G.729a, G.729ab
Operating Temperature	32 to 104°F (0 to 40°C)
Humidity	10% to 90% non-condensing
Network Interface	1 x 10/100 Ethernet
Protocol Support	SCCP, SIP
Power Supply	AC 100-240V, 50-60Hz
Weight	2.2 lbs (1 kg)
Storage Temperature	-20 to 70°C
