Setting Up and Configuring the WRVS4400N Wireless-N Router
Configuring the L2 Switch Settings
Cisco WRVS4400N Wireless-N Gigabit Security Router with VPN Administration Guide 150
5
Mirroring Ports
The L2 Switch > Port Mirroring window displays the settings for configuring port
mirroring for the router.
To configure L2 switch port mirroring, follow these steps:
STEP1 Click L2 Switch > Port Mirroring.
STEP 2 Configure the L2 switch port mirroring settings for the router:
• Mirror Source—Enable or disable source port mirroring for each port on the
router. To enable source port mirroring on a port, check the box next to that
port. To disable source port mirroring on a port, leave the box unchecked.
The default is disabled.
• Mirror Port—Select the mirror destination port from the drop-down menu.
