32
——
7.
Slide the head balance adjustment slider located near the thermal head along the media
size scale (inch) so that the position of the notch in the slider matches the media width.
2
”
3
”
4
”
4.65
”
1
”
Head balance
adjustment slider
media
size scale
Thermal
printhead
CAUTION
Adjust the head pressure horizontal balance carefully so as not to damage the thermal head.
Damaged thermal heads will result in poor printing, paper jams, and malfunction.
If using media in thermal-transfer printing with a width of 2 inches or less, we recommend set-
ting the head balance adjustment slider to 2.5” (between 2” and 3”).
8. Close the top cover.
CAUTION
Press the push marks on left and right sides at the top of the top cover and ensure that the top
cover hooks on each side lock securely.
If the top cover is not securely locked, this may cause print errors, paper jams, and malfunction.
To Next Page
