Citizen CL-E331 User Manual

63
——
5. Conguring Ethernet Network
Settings Using Network Seeker
You can check and change the settings of the wired LAN interface board by using
CITIZEN Network Seeker, which is utility software that runs in Windows.
5.1 Starting Network Seeker
After obtaining the program “NetSeeker.exe” from the CD-ROM or our website, double
click the program. A dialog box appears.
Start a search for printers by clicking the Seek button.
1
4
3
6
8
7
5
2
1. “Seek” button
Start a search for Ethernet interface boards on the network.
Waits for a response during the time congured with [Communication timeout].
2. “Edit cong” button
Change the settings of the selected board.
3. Board information list
Single click to select a board and double click to change settings.

Citizen CL-E331 Specifications

General

Product color	Black
Print technology	Thermal transfer
Printing media thickness	63.5 - 190 µm
Sustainability compliance	Yes
Sustainability certificates	CE, Federal Communications Commission (FCC), TUV, UL ECOLOGO, VCCI
Display	-
Control type	Buttons
Color	No
Maximum resolution	- DPI
Printable dot numbers	300 dot
Ribbon width	60 mm
Core diameter	25 mm
Ribbon length	300 m
Media thickness	0.150 mm
Maximum label width	118 mm
Maximum media length	1625.6 mm
Maximum roll diameter	125 mm
RS-232 ports	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Flash memory	16 MB
Internal memory	32 MB
Built-in barcodes	CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, GS1 DataBar, ITF, PDF417, QR Code, UPC-A, UPC-E
Server operating systems supported	Windows Server 2012, Windows Server 2016, Windows Server 2019, Windows Server 2022
Windows operating systems supported	Windows 10, Windows 11, Windows 7

Weight and Dimensions

Depth	266 mm
Width	178 mm
Height	173 mm
Weight	2600 g
Label width	104 mm
