Citizen CL-E331 User Manual

64
——
4. Board information
Single click to select a board and double click to change settings.
5. Conguration display section
View the settings of the selected board.
6. Client condition display
When “Busy” is displayed, operations to search, change settings, and so on are
prohibited.
If you click “Stop”, the “Busy” status is cleared forcibly.
7. Communication timeout
You can congure the time-out duration for searches and other operations.
8. Status log
View the status of the utility.
5.2 Changing Settings
You can congure an Ethernet interface board by selecting it at the main dialog box,
and then clicking “Edit cong”.
 These are unalterable parameters.
These parameters are for display purposes only.
1
2
3
4
5

Citizen CL-E331 Specifications

General

Product color	Black
Print technology	Thermal transfer
Printing media thickness	63.5 - 190 µm
Sustainability compliance	Yes
Sustainability certificates	CE, Federal Communications Commission (FCC), TUV, UL ECOLOGO, VCCI
Display	-
Control type	Buttons
Color	No
Maximum resolution	- DPI
Printable dot numbers	300 dot
Ribbon width	60 mm
Core diameter	25 mm
Ribbon length	300 m
Media thickness	0.150 mm
Maximum label width	118 mm
Maximum media length	1625.6 mm
Maximum roll diameter	125 mm
RS-232 ports	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Flash memory	16 MB
Internal memory	32 MB
Built-in barcodes	CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, GS1 DataBar, ITF, PDF417, QR Code, UPC-A, UPC-E
Server operating systems supported	Windows Server 2012, Windows Server 2016, Windows Server 2019, Windows Server 2022
Windows operating systems supported	Windows 10, Windows 11, Windows 7

Weight and Dimensions

Depth	266 mm
Width	178 mm
Height	173 mm
Weight	2600 g
Label width	104 mm
