Citizen CL-E331 User Manual

46
——
Adjusting the Left/Right Balance of the Ribbon
If the left/right balance of the ribbon needs to be adjusted, adjust it by moving the
ribbon left/right balance adjustment knob.
If wrinkles are occurring in the ribbon, make the adjustment described in the following
procedure.
Ribbon
Initial setting
position
Ribbon left/right balance
adjustment knob
1. Check on which of the left and right sides that slack occurs when looking from the
front of the ribbon.
CAUTION
If this cannot be determined easily when the ribbon is in a stationary state, perform printing and
check the part where the wrinkles actually occur.
2. Loosen the screw xing the ribbon left/right balance adjustment knob.
Screw
Ribbon

Citizen CL-E331 Specifications

General

Product color	Black
Print technology	Thermal transfer
Printing media thickness	63.5 - 190 µm
Sustainability compliance	Yes
Sustainability certificates	CE, Federal Communications Commission (FCC), TUV, UL ECOLOGO, VCCI
Display	-
Control type	Buttons
Color	No
Maximum resolution	- DPI
Printable dot numbers	300 dot
Ribbon width	60 mm
Core diameter	25 mm
Ribbon length	300 m
Media thickness	0.150 mm
Maximum label width	118 mm
Maximum media length	1625.6 mm
Maximum roll diameter	125 mm
RS-232 ports	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Flash memory	16 MB
Internal memory	32 MB
Built-in barcodes	CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, GS1 DataBar, ITF, PDF417, QR Code, UPC-A, UPC-E
Server operating systems supported	Windows Server 2012, Windows Server 2016, Windows Server 2019, Windows Server 2022
Windows operating systems supported	Windows 10, Windows 11, Windows 7

Weight and Dimensions

Depth	266 mm
Width	178 mm
Height	173 mm
Weight	2600 g
Label width	104 mm
