Citizen CL-E331 User Manual

61
——
Home menu Sub menu Default Congurable range Notes
Interface - 2
*1
Timeout 60 0 - 300 Timeout time (in seconds) for con-
nection with host machine
When the set number of sec-
onds elapses without data being
received from the host in the state
in which a session is established,
a timeout occurs and the session
is disconnected. If this is set to 0,
there will be no timeout.
Action at
timeout
Close all Close all
Move next
Pending session processing when
timeout
Sets whether to disconnect all
other sessions or to enable send-
ing and receiving when there are
two or more sessions established
and a timeout occurs for the ses-
sion that was established rst
Transmits
buffered data
Disable Disable
Enable
Transmission data processing
when host machine not connected
IPv6 On On
Off
Enables/disables IPv6
Fixed
IPv6 Address
On On
Off
Enables/disables IPv6 static net-
work address
IPv6 Address
0.0.0.0.0.0.0.0.
0.0.0.0.0.0.0.0
0.0.0.0.0.0.0.0.
0.0.0.0.0.0.0.0 -
255.255.255.255.255.
255.255.255.255.255.
255.255.255.255.255.255
Sets a IPv6 network address
Example: If the network address
you wish to set is 2001:0db8:0000:
0123:4567:89ab:cdef:feed, specify
the value for each network address
eld in decimal notation separated
by periods as shown below.
32.1.13.184.0.0.1.35.69.103.137.1
71.205.239.254.237
IPv6 Prex
Length
64 1 - 128 IPv6 prex length setting (in bits)
IPv6 Gateway
0.0.0.0.0.0.0.0.
0.0.0.0.0.0.0.0
0.0.0.0.0.0.0.0.
0.0.0.0.0.0.0.0 -
255.255.255.255.255.
255.255.255.255.255.
255.255.255.255.255.255
IPv6 gateway address setting
For how to specify an address,
refer to the Notes column in “IPv6
Address”.
*1 Contains menus of option interface settings that can be congured for this printer.

Citizen CL-E331 Specifications

General

Product color	Black
Print technology	Thermal transfer
Printing media thickness	63.5 - 190 µm
Sustainability compliance	Yes
Sustainability certificates	CE, Federal Communications Commission (FCC), TUV, UL ECOLOGO, VCCI
Display	-
Control type	Buttons
Color	No
Maximum resolution	- DPI
Printable dot numbers	300 dot
Ribbon width	60 mm
Core diameter	25 mm
Ribbon length	300 m
Media thickness	0.150 mm
Maximum label width	118 mm
Maximum media length	1625.6 mm
Maximum roll diameter	125 mm
RS-232 ports	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Flash memory	16 MB
Internal memory	32 MB
Built-in barcodes	CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, GS1 DataBar, ITF, PDF417, QR Code, UPC-A, UPC-E
Server operating systems supported	Windows Server 2012, Windows Server 2016, Windows Server 2019, Windows Server 2022
Windows operating systems supported	Windows 10, Windows 11, Windows 7

Weight and Dimensions

Depth	266 mm
Width	178 mm
Height	173 mm
Weight	2600 g
Label width	104 mm
