- 379 -
fn=80: Function 380 Storing 2D GS1 DataBar data to 2D code data storage area
GS ( k pL pH cn fn m n d1 … dk
[Code] <1D>H<28>H<6B>H<pL><pH><cn><fn><m><n><d1…dk>
[Range] 6≦(pL + pH×256)≦259 (0≦pL≦255、pH＝0,1)
cn＝51
fn＝80
m＝48
n＝72,73,76
k＝(pL＋pH×256) – 4
Range of d is different depending on type of GS1 Databar specified by n.
GS1 DataBar Stacked and GS1 DataBar Stacked Omnidirectional are same as GS1 DataBar
Omnidirectional.
GS1 DataBar Expanded Stacked is same as GS1 DataBar Expanded.
[Outline] [The specification which is common to the model]
• Stores 2-dimensional GS1 DataBar code data (d1…dk) to 2-dimensional code data
storage area.
n
Barcode
72
GS1 DataBar Stacked
73
GS1 DataBar Stacked Omnidirectional
76
GS1 DataBar Expanded Stacked
fn=81: Function 381 Printing 2D GS1 Databar data in 2D code data storage area
GS ( k pL pH cn fn m
[Code] <1D>H<28>H<6B>H<pL><pH><cn><fn><m>
[Range] (pL＋pH×256)＝3 (pL＝3、pH＝0)
cn＝51
fn＝81
m＝48
[Outline] [The specification which is common to the model]
• Prints GS1 DataBar code data stored in 2-dimensional code data storage area.
