The following table lists the settings used in this example.
Entity Name Details
IP address of clients CL1 192.0.2.10
CL2 192.0.2.20
IP address of servers S1 198.51.100.19
S2 198.51.100.20
S3 198.51.101.19
S4 198.51.101.20
SNIP addresses on NS1 198.51.100.18
198.51.101.18
MTU specified for interfaces and VLANs on
NS1
10/1 9216
10/2 9216
VLAN 10 9000
