© 1999-2017 Citrix Systems, Inc. All rights reserved. p.114https://docs.citrix.com
VLAN 20 9000
VLAN 30 9000
VLAN 40 1500
Default TCP profile nstcp_default_profile MSS: 1460
Custom T CP profile ALL-JUMBO MSS: 8960
Services on NS1 representing servers SVC-S1 IP address: 198.51.100.19
Protocol: HT TP
Port: 80
TCP profile: ALL-JUMBO (MSS: 8960)
SVC-S2 IP address: 198.51.100.20
Protocol: HT TP
Port: 80
TCP profile: ALL-JUMBO (MSS: 8960)
SVC-S3 IP address: 198.51.101.19
Protocol: HT TP
Port: 80
TCP profile: nstcp_default_profile
(MSS:1460)
SVC-S4 IP address: 198.51.101.20
Protocol: HT TP
Port: 80
TCP profile: nstcp_default_profile
(MSS:1460)
Load balancing virtual servers on NS1 LBVS-1 IP address = 203.0.113.15
Protocol: HT TP
Port:80
Bound services: SVC-S1, SVC-S2
TCP profile: ALL-JUMBO (MSS: 8960)
LBVS-2 IP address = 203.0.114.15
Protocol: HT TP
Port:80
Bound services: SVC-S3, SVC-S4
Entity Name Details
