Autonegotiation is enabled by default on the 10G SFP+ ports into which you insert your 10G SFP+ transceiver. As soon as a
link between the port and the network is established, the mode is matched on both ends of the cable and for 10G SFP+
transceivers, the speed is also autonegotiated.
This section applies to the following SDX models:
SDX 8015/8400/8600
SDX 11500/13500/14500/16500/18500/20500
SDX 11515/11520/11530/11540/11542
SDX 14020/14030/14040/14060/14080/14100
SDX 14020-40G/14040-40G/14060-40G/14080-40G/14100-40G
SDX 14040-40S/14060-40S/14080-40S/14100-40S
SDX 14030 FIPS/14060 FIPS/ 14080 FIPS
SDX 17500/19500/21500
SDX 17550/19550/20550/21550
SDX 22040/22060/22080/22100/22120
SDX 24100/24150
SDX 25160A/25100A
SDX 25160A-40G/25100A-40G
Important
NetScaler appliances do not support support 40G QSFP+/10G SFP+ transceivers provided by vendors other than Citrix Systems.
Attempting to install third-party support 40G QSFP+/10G SFP+ transceivers on your NetScaler appliance voids the warranty.
Insert the support 40G QSFP+/10G SFP+ transceivers into the support 40G QSFP+/10G SFP+ ports on the front panel of
the appliance. Frequent installation and removal of transceivers shortens their life span. Follow the removal procedure
carefully to avoid damaging the transceiver or the appliance.
Warning
Do not install the transceivers with the cables attached. Doing so can damage the cable, the connector, or the optical interface of the
transceiver.
To install a support 40G QSFP+/10G SFP+ transceiver
1. Remove the support 40G QSFP+/10G SFP+ transceiver carefully from its box.
2. Align the support 40G QSFP+/10G SFP+ transceiver to the front of the support 40G QSFP+/10G SFP+ transceiver port
on the front panel of the appliance.
3. Hold the support 40G QSFP+/10G SFP+ transceiver between your thumb and index finger and insert it into the support
40G QSFP+/10G SFP+ transceiver port, pressing it in until you hear the transceiver snap into place.
4. Move the locking hinge to the DOWN position.
5. Verify that the LED is green and blinks twice, which indicates that the transceiver is functioning correctly.
6. Do not remove the dust caps attached to the transceiver and cable until you are ready to insert the cable.
To remove a support 40G QSFP+/10G SFP+ transceiver
