Activity
Solid green Link is established but no traffic is passing through the
port.
Blinking
green
Traffic is passing through the port.
Management
(RJ45)
Left Speed Off No connection, or a traffic rate of 10 megabits per
second (Mbps).
Green Traffic rate of 100 Mbps.
Amber Traffic rate of 1 gigabit per second.
Right Link/
Activity
Off No link.
Solid yellow Link is established but no traffic is passing through the
port.
Blinking
yellow
Traffic is passing through the port.
Port T ypePort T ype LEDLED
Locat ionLocat ion
LEDLED
Funct ionFunct ion
LED ColorLED Color LED Indicat esLED Indicat es
On each power supply, a bicolor LED indicator shows the condition of the power supply.
T able 2. LED Power Supply Indicat orsT able 2. LED Power Supply Indicat ors
Power Supply T ypePower Supply T ype LED ColorLED Color LED Indicat esLED Indicat es
AC OFF No power to any power supply.
Flashing RED No power to this power supply.
Flashing GREEN Power supply is in standby mode.
GREEN Power supply is functional.
RED Power supply failure.
DC OFF No power to any power supply.
Flashing RED No power to this power supply.
