111
ENGINE
AUXILIARY EQUIPMENT DRIVE BELT
Without power-assisted steering
Tools :
[1] Belt tension measuring instrument : 4122-T.
Removal.
- Loosen the screws (2).
- Tighten the screw (1) until it is against its stop.
- Remove the belt.
Refitting.
- Refit the belt.
- Fit the tool [1] on the belt at "d".
- Tighten the screw (1) to obtain : 106 ± 10 SEEM units.
- Tighten the screws (2) to 2 m.daN.
- Remove the tool [1].
B1BP1SECB1BP1SDC
Engine : WJY
XSARA
