112
ENGINE
XSARA
AUXILIARY EQUIPMENT DRIVE BELT
Without power-assisted steering, with air conditioning
Tools :
[1] Belt tension measuring instrument : 4122-T.
Removal.
- Loosen the screws (1).
- Tighten the screw (2) until it is against its stop.
- Remove the belt.
Refitting.
- Refit the belt.
- Fit the tool [1] at "e".
- Tighten the screw (2) to obtain : 106 ± 10 SEEM units.
- Tighten the screws (1) to 2 m.daN.
- Remove the tool [1].
B1BP1SGCB1BP1SFC
Engine : WJY
