113
ENGINE
XSARA
AUXILIARY EQUIPMENT DRIVE BELT
Power-assisted steering, without air conditioning
Tools :
[1] Belt tension measuring instrument : 4122-T.
Removal.
WARNING : If the belt is to be reused, measure the tension before removal.
- Loosen :
- the screw (1).
- the nut (2).
NOTE : The tensioner arm (3) must be against the alternator.
- Remove the belt.
B1BP1SHD
Engine : WJY
