30
• Connecting to the external amplier
 Externalamplierscanbeconnectedtothe4channelRCAoutputconnections.
Ensure that the connectors are not grounded or shorted to prevent damage to the
unit.
8) Connecting the Accessories
Front right
Front left
Front right
Front left
Front right
Front left
Not used.
Insulateeachwire
Gray
16-pin connector extension lead
(attachedtothesourceunit)
Gray/Black
White
White/Black
Purple
Purple/Black
Green
Green/Black
Gray
Gray/Black
White
White/Black
Purple
Purple/Black
Green
Green/Black
Yellowwire(Memoryback-uplead)
Connectdirectlytobattery
Redwire(Powerlead)
Accessory
12V
Blue/Whitewire(Amplierturn-onlead)
Connecttoremoteturn-onleadofamplier
Blackwire(Groundlead)
Connect to vehicle chassis ground
Orange/Whitewire(Illuminationlead)
Connectittothecarpowersupplyterminal
for illumination
Bluewire(Autoantennalead)
Connectittothecarpowersupplyterminal
for antenna
4-speaker system
or
2-speaker system
