Clarion NX502E User Manual

41
English
NX502E
Video Out
Rear Vision Camera
Yellow
VISUAL IN
Black
Yellow
CAMERA
Black
Red
White
AUX IN 2
Red
External Microphone
Connection
Black
Black
GPS Antenna
(Black)
Black
DAB
Black
Black
USB connector
Red
White
Line Out
Front Right
Line Out
Front Left
Gray
Red
White
Line Out
Rear Right
Line Out
Rear Left
Black
Red
White
Subwoofer 1
Subwoofer 2
Purple
Yellow
VIDEO OUT
Black
Red
White
2 ZONE OUT
Green
Radio Antenna
(Black)
DAB302E (sold separately)
NX502E
Steering Wheel Remote Control Terminal
Gray
Gray
C
18
16
14
12
10
8
6
4
2
17
15
13
11
9
7
5
3
1
A
1
3
5
7
2
4
6
8
B
1
3
5
7
2
4
6
8
Phone Mute / Brown
Reverse / Purple with white stripe
Rear right (+) / Purple
Rear right (-) / Purple with black stripe
Rear left (+) / Green
Rear left (-) / Green with black stripe
Front right (+) / Grey
Front right (-) / Grey with black stripe
Front left (+) / White
Front left (-) / White with black stripe
Battery 12V(+) / Yellow
Auto Antenna / Blue
Illumination / Orange with white stripe
ACC+ / Red
Ground / Black
YellowYellow
RedRed
VW , Audi
Battery +
Front left +
Rear left +
Rear right -
Front right -
Rear left -
Front left -
Front right +
Rear right +
Fuse 15A
Refer to next page.
A
B
C
2
4
6
8
1
3
5
7
1
3
5
7
2
4
6
8
Reverse
Phone Mute
Parking
Illumination
Ground
AMP Remote
AUTO ANT
ACC +
Video Out
iPod/iPhone
CCA-750 (sold separately)
6-Channel Amplifier
USB Memory
Video In
Audio In
Rear Zone
Monitor
or
18. WIRING AND CONNECTIONS
(Black)
(Black)
(Black)
(Black)
Radio Antenna
Refer to next page.
Red
Black
VISUAL IN
VIDEO OUT
2 ZONE OUT
CAMERA
Black
Black
Black
DAB
Black
Green
Gray
Gray
Gray
Black
Black
or
USB Memory
6-Channel Amplier
USB connector
Purple
Red
Red
Red
Red
Red
Line Out
Front Right
Line Out
Rear Right
Line Out
Front Left
Line Out
Rear Left
Subwoofer 1
Subwoofer 2
iPod/iPhone
Video Out
Video Out
Video In
Steering Wheel Remote Control Terminal
Audio In
DAB302E (sold separately)
Rear Zone
Monitor
Rear Vision Camera
CCA-750 (sold separately)
White
White
White
White
White
Yellow
Yellow
Yellow
AUX IN 2
GPS Antenna
External Microphone
Connection

Clarion NX502E Specifications

General

MP3 playback	Yes
CD-R playback	-
Audio formats supported	MP3, WMA
Video formats supported	MPEG4
USB version	2.0
Bluetooth profiles	A2DP, AVRCP, DUN, HFP, HSP, OPP, PBAP
USB ports quantity	1
Headphone connectivity	3.5mm
DIN size	2 DIN
Output power	200 W
Product color	Black
Disc types supported	DVD, DVD+R, DVD+RW, DVD-R, DVD-RW
Audio output channels	4.0 channels
Maximum power per channel	50 W
Analog signal format system	NTSC, PAL
Signal-to-Noise Ratio (SNR)	93 dB
AM band range	531 - 1602 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM, MW
Preset stations quantity	22
Aspect ratio	16:9
Display type	TFT
Display diagonal	6.2 \
Compatible memory cards	SD
Menu languages	CZE, DEU, DUT, ENG, ESP, FRE, GRE, ITA, POL, SWE
Key illumination color	Multi
