-4- Clarke
®
Operator's Manual (EN) - Image 16 I/IX 120V
INTRODUCTION AND MACHINE SPECIFICATIONS
The Image 16 is an extractor for cleaning the carpet. The machine applies cleaning solution to the carpet and
removes dirty solution and soil from the carpet. The Image 16 is equipped with a power brush. The extractor has
controls to start the solution pump, and vacuum motor. The extractor (floor spray and brush) can be operated
intermittently or continuously. This machine is intended for commercial use.
Specifications:
Image 16i Image 16ix
120V 120V
Model 04110B 04111B
Solution Pump 100 PSI Fixed 0-100 PSI Variable
Power Cable 35' 3-wire 50' 3-wire disconnect
Spray Jets 4 Q.C. front, 1 Q.C. rear
Solution Tank Capacity 8 Gallons 8½ Gallons
Recovery Tank 7½ Gallons 7½ Gallons
Waterlift/CFM 140"/101
Vacuum Tangential discharge, 2 HP, 3 stage
Electrical 120 Volt 50/60 Hz
Brush Size 3" x 13"
Brush Motor Size
1
/8 HP
Dimensions 33" x 46" x 16"
Weight 101 lbs.
Shipping Weight 140 lbs.
DANGER: Machines can cause an explosion when operated near flammable materials and vapors. Do not
use this machine with or near fuels, grain dust, solvents, thinners, or other flammable materials.
WARNING: You must have training in the operation of this machine before using it. READ THE
INSTRUCTION BOOK FIRST.
WARNING: Do not use this machine as a step or furniture. Injury could occur to the operator.
WARNING: To avoid serious injury, use proper lifting procedures when lifting the machine.
WARNING: Make sure that all the labels, decals, warnings, cautions and instructions are readable. Replace
them when necessary by ordering them from Clarke.
WARNING: Do not use water that is hotter than 140
°
F.
WARNING: Improper discharge of waste water may damage the environment and be illegal. The United
States Environmental Protection Agency has established certain regulations regarding
discharge of waste water. Also, city and state regulation regarding this discharge may be in
effect in your area. Understand and follow the regulations in your area. Be aware of the
environmental hazards of chemicals that you dispose.
