CleaverBrooks FLE - Page 11

Table 1-1 cont’d
PARTS HIGH PRESSURE STEAM LOW PRESSURE STEAM
DESCRIPTION INFO 150-250 300-350 400-600 700-900 1000-1200 150-250 300-350 400-600 700-900 1000-1200
Base Assembly PART NO 315-1224 315-1169 315-1180 315-1194 315-1203 315-1224 315-1169 315-1180 315-1194 315-1203
(Insulated) APPROX. SIZE (in) 60x42 74x45-1/2 95x47-1/2 116x53-1/2 140x53-1/2 60x42 74x45-1/2 95x47-1/2 116x53-1/2 140x53-1/2
WEIGHT (lbs) 630 710 950 1440 11690 630 710 950 1440 11690
Front Wall PART NO 315-1216 315-1229 315-1238 315-1249 315-1249 315-1216 315-1229 315-1238 315-1249 315-1249
Large Piece APPROX. SIZE (in) 77x33 81x37 85x39 97x45 97x45 77x33 81x37 85x39 97x45 97x45
(Insulated) WEIGHT (lbs) 110 125 125 170 170 110 125 125 170 170
Front Wall PART NO 315-1286 315-1288 315-1290 315-1292 315-1292 315-1286 315-1288 315-1290 315-1292 315-1292
Corner Piece APPROX. SIZE (in) 32x17 36x19 34x20 40x23 40x23 32x17 36x19 34x20 40x23 40x23
(Insulated)WEIGHT (lbs)20253035352025303535
Rear Wall PART NO 315-1217 315-1228 315-1237 315-1248 315-1248 315-1217 315-1228 315-1237 315-1248 315-1248
Large Piece APPROX. SIZE (in) 77x33 81x37 85x40 97x46 97x46 77x33 81x37 85x40 97x46 97x46
(Insulated) WEIGHT (lbs) 130 145 155 210 210 130 145 155 210 210
Rear Wall PART NO 315-1285 315-1287 315-1289 315-1291 315-1291 315-1285 315-1287 315-1289 315-1291 315-1291
Corner Piece APPROX. SIZE (in) 40x21 44x23 42x24 40x23 40x23 40x21 44x23 42x24 40x23 40x23
(Insulated)WEIGHT (lbs)25303540402530354040
Roof Assembly PART NO 315-1215 315-1230 315-1239 315-1250 315-1260 315-1215 315-1230 315-1239 315-1250 315-1260
(Insulated) APPROX. SIZE (in) 68x34 74x37 95x40 116x45 140x45 68x34 74x37 95x40 116x45 140x45
WEIGHT (lbs) 185 215 280 370 430 185 215 280 370 430
Upper Drum PART NO 270-1527 270-1528 270-1529 270-1530 270-2510 270-1523 270-1524 270-1525 270-1526 270-2582
Assembly APPROX. SIZE (in) 20x98 20x104 20x126 24x150 24x182 20x98 20x104 20x126 24x150 24x182
WEIGHT (lbs) 890 930 1075 1500 1750 975 1020 1170 1660
1910
Lower Drum PART NO 270-1519 270-1520 270-1521 270-1522 270-2513 270-1515 270-1516 270-1517 270-1518 270-2581
Assembly APPROX. SIZE (in) 8x96 8x104 10x126 10x150 10x182 8x96 8x104 10x126 10x150 10x182
WEIGHT (lbs) 310 325 515 600 705 310 325 515 600
705
Inner Casing PART NO * * * * * * * * * *
Panels APPROX. SIZE (in) 76x32 83x35 87x32 100x30 100x28 76x32 83x35 87x32 100x30 100x28
(Insulated)WEIGHT (lbs)57606355555760635555
Outer Casing PART NO 315-1218 315-1227 315-1236 315-1247 315-1257 315-1218 315-1227 315-1236 315-1247 315-1257
Panels APPROX. SIZE (in) 80x22 84x23 88x23 100x23 100x23 80x22 84x23 88x23 100x23 100x23
(Insulated)WEIGHT (lbs)42484345444248434544
Burner Door PART NO ** ** ** ** ** ** ** ** ** **
APPROX. SIZE (in) 20x20 20x20 26x26 26x26 26x26 20x20 20x20 26x26 26x26
26x26
WEIGHT (lbs) 120 120 240 240 240 120 120 240 240
240
Tubes PART NO 93-3200 93-3200 93-3200 93-3200 93-2729 93-3200 93-3200 93-3200 93-3200 93-2729
APPROX. SIZE (in) 25-3/4x60 29-37x64 36-3/4x67 38-3/4x77
38-3/4x77
25-3/4x60 29-37x64 36-3/4x67 38-3/4x77
38-3/4x77
WEIGHT (lbs) 1400 1700 2500 3600
4400
1400 1700 2500 3600
4400
TOTAL WEIGHT 5700 5700 6200 7900 10200 11700 6200 7900 10200 11700
* Various part numbers are used for each size
** Part number depends on burner size required.
