42
St e p 11
Tighten Rear-Facing LATCH Belt to secure the
car seat.
• Press down in center of car seat to
depress the vehicle seat cushion and
pull free end of Rear-Facing LATCH Belt
to tighten as shown in Figure 51.
• Repeat for opposite side of Rear-Facing
LATCH Belt.
Step 12
Close both Rear-Facing Belt Lock-offs, as
shown in Figure 52.
Step 13
Check for secure installation. Gripping car
seat at top of armrests, pull car seat front
to back and left to right to check for secure
installation as shown in Figure 53. Rear-
Facing LATCH Belt must stay tight and car
seat should not move more than 1 in. (2.5 cm)
in any direction.
• If Rear-Facing LATCH Belt does not stay
tight or car seat cannot be securely
installed, try a different LATCH location
or install using the vehicle belt, see
“Installing Rear-Facing Car Seat With
Vehicle Belt” on page 46.
Figure 53
Figure 52
Figure 51
