49
Figure 63
Step 7
Route vehicle belt through the Rear-Facing
Belt Path and under both forward Belt Tabs,
and buckle vehicle belt, as shown in
Figure 63.
Check that Crotch Strap is not under the
vehicle belt.
Step 8
Tighten vehicle belt to secure the car seat
• Press down in center of car seat to
depress the vehicle cushion and pull the
shoulder portion of lap/shoulder belt to
tighten as shown in Figure 64, or pull
free end of the lap belt (for lap-only belt
installation) as shown in Figure 65.
Figure 64 Figure 65
