RADIUS SL PLUS 03.2019 en 25
6.3.2 Lifting the machine with belts and chains
Attention:
Always switch off the drive and engine when leaving the tractor for mounting, dismounting or
making adjustments.
Remove ignition key!
Secure the tractor and machine against unintentional movements (e.g. rolling away, lowering,
etc.).
Observe the relevant accident prevention regulations and all other information given in the
operating instructions!
When attaching or removing implements to the tractor do not step between tractor and
implement!
Always use the attachment point when lifting the machine. Remove the lateral protective cover. To lift, you can
now insert a suitable belt into this opening and lead it upwards through the opening for the front tool. If the edges
are sharp, use an edge protector.
Attention: The RADIUS can tip over when the screws are loosened.
Never step under suspended loads! Ensure that the hoist is sufficiently dimensioned and tested and
observe the applicable accident prevention regulations when handling hoists and suspended loads!
Figure 33 Attachment point
Lead the belt through this opening.
