RADIUS SL PLUS 03.2019 en 52
10.16 Conversion kit Rotary Cultivator Reverse
(Connection diagram for Rotary Cultivator 2-sided)
A = return oil hose
B = Leak oil hose
Figure 54 Spare parts Conversion kit Rotary Cultivator Reverse
Flow direction
==>
<===
Flow direction
1
===>
===>
===>
B
===>
===>
===>
A
12
7
9
Tank
Flow divider
Rotary Cultivator lhs CA.917.150000
Rotary Cultivator rhs CA.917.050000
Pressure side
Leak oil hose
Bridge hose
B
2
3
8
6
4
10
13
5
11
direction of
motor rotation
direction of
motor rotation
A
