Clemens Technologies RADIUS SL PLUS - Constant flow divider (adjustable 1-25 L)

RADIUS SL PLUS 03.2019 en 77
10.33 Constant flow divider adjustable 1-25 l (0.25-6.60 gal.)
Figure 71 Spare parts Constant flow divider adjustable 1-25 l (0.25-6.60 gal.)
Item no.
Specification
Remark
Quantity
Order no.
Constant flow regulator adjustable 1-25 l
(0.25-6.60 gal.)
complete
CC845.463200
1
Pipe bend
1
CC845.463202
2
Screw-in fitting
from 2018, with nut and
ferrule
1
CW730.031800
3
Union nut
1
CW011.600600
4
Straight screw socket
with nut and ferrule
2
CW730.004900
5
Fitting
1
CW730.008600
6
Angular fitting
1
CW730.010400
7
Union nut
3
CW730.012000
8
Ferrule
6
CW730.012100
9
Straight fitting
1
CW730.015000
10
Adjustable T-fitting
with nut and ferrule
1
CW730.077100
11
Straight screw socket
1
CW730.079200
12
Oil flow divider
1
CW760.009100
3
12
7
4
8
2
11
4
1
7
8
9
8
7
10
5
6
