RADIUS SL PLUS 03.2019 en 61
10.22 Disk plow ø 350 mm (13.8“)
Figure 60 Spare parts Disk plow ø 350 mm (13.8")
Item no.
Specification
Remark
Quantity
Order no.
Disk plow ø 350 mm (13.8”)
indented
CB926.920000
alternatively:
Disk plow ø 350 mm (13.8”)
plain
CC926.920000
1
Bowed leg
1
CB926.920100
1.1
Serrated disc ø 65 mm (2.5“), for welding
available separately
CW902.002300
2
Support
1
CB926.920200
3
Lock washer
5
CW520.002900
4
Retaining washer
1
CW520.009900
5
Bearing unit
1
CW540.047900
6
Disk 350 mm (13.8”)
indented
1
CW650.019300
alternatively:
Disk 350 mm (13.8”)
plain
CW650.019500
7
Hexagon head screw
1
096016065
8
Hexagon head screw
5
096112020
9
Hexagon nut
1
09852420
1
2
3
4
5
6
7
8
9
1.1
