Clemens Technologies RADIUS SL PLUS User Manual

RADIUS SL PLUS 03.2019 en 33
Item no.
Specification
Remark
Quantity
Order no.
1
Bracket rhs
1
CL860.011000
1
Bracket lhs
1
CL860.111000
2
Cover
2
CL860.010100
3
Clamping plate
1
CL856.010002
4
Company logo CLEMENS RADIUS SL
1
CL861.010012
5
Limiting bushing high
1
CL860.050002
6
Disk
1
CW007.004700
7
Leg spring high rhs
1
CW009.042100
7
Leg spring high lhs
1
CW009.042200
8
Deep groove ball bearing
3
CW540.064400
9
Spring washer
1
012714
10
Circlip ring
1
047272
11
Fitted screw
1
061014060s
12
Setscrew
1
091308025s
13
Hexagon screw
1
093108060
14
Hexagon screw
2
093312055
15
Hexagon nut
1
093408
16
Hexagon nut
1
093414
17
Hexagon nut
1
098508
18
Adjusting. washer
1
0988152105
19
Adjusting. washer
1
0988152110
20
Washer
2
144012
21
Bind rivet
4
7337030062A
