Clemens Technologies RADIUS SL PLUS User Manual

RADIUS SL PLUS 03.2019 en 47
Item no.
Specification
Remark
Quantity
Order no.
Rotary Cultivator rhs complete
CA917.050000
Rotary Cultivator lhs complete
CA917.150000
1
Base module rhs
1
CA917.051000
1
Base module lhs
1
CA917.151000
2
Plate unit
1
CA917.052000
3
Cover assembly
1
CA917.053000
4
Deflector
1
CA917.050001
5
Straight tine
3
CA917.050002
7
Sticker "Direction sign"
1
CW002.001500
8
Sticker "Only touch machine parts..."
1
CW002.008400
9
Lock washer
2
CW520.002700
10
Lock washer
4
CW520.002800
11
Lock washer
3
CW520.002900
12
Lock washer
6
CW520.003100
13
Deep grove ball bearing
2
CW540.035600
14
Screwing plug
2
CW600.090100
15
Hydraulic motor
1
CW750.005200
for 15
Seal kit for hydraulic motor
1
CW750.005202
16
Connector block
1
CW750.005201
17
Washer
3
012508
18
Circlip ring
1
047170s
19
Socket head cap screw
4
091208040
20
Hexagon head screw
2
093108080
21
Hexagon head screw
3
093116060
22
Hexagon head screw
3
093308022
23
Hexagon head screw
4
093310025
24
Hexagon head screw
3
093312035
25
Hexagon nut
3
093412
26
Hexagon nut
3
093416
27
Notched nail
2
147603006
28
Spring washer
4
798008s
29
Gasket
from serial number 917.050221
1
CW780.027800
oder 29
Adjusting washer
see note
1
CA917.050003
Note:
If only a base module item no. 2 or only a plate unit item no. 3 is required for devices with
serial numbers up to 917.050220, the adjusting washer item no. 29 is required instead of the
gasket item no. 29.
