Clemens Technologies RADIUS SL PLUS User Manual

RADIUS SL PLUS 03.2019 en 69
Item no.
Specification
Remark
Quantity
Order no.
Oil flow divider 50/50
complete items no. 1 - 7 standard
+ item no. 9
CF856.092000
1
Flow divider / Return oil manifold
complete items no. 1.1 - 1.4
1
CA895.381000
1.1
Valve housing
1
CA895.381001
1.2
Control piston
1
CL895.381002
1.3
Closing screw
3
CW011.006100
1.4
Pressure spring
2
CW009.005500
2
Coupling plug SVK
standard
1
CW720.000200
Coupling sleeve SVK
e.g. for Fendt
CW720.003600
Coupling plug flat
e.g. for Holder
CW720.000700
3
Coupling plug SVK
standard
1
CW720.001000
Coupling sleeve SVK
e.g. for Fendt
CW720.000600
Coupling plug flat
e.g. for Holder
CW720.004200
4
Dust cover for coupling plug SVK
standard
1
CW720.005900
(CW720.006000)
Dust cover for coupling sleeve SVK
e.g. for Fendt
CW720.007900
Dust cover for coupling plug flat
e.g. for Holder
CW720.005300
5
Dust cover for coupling plug SVK
standard
1
CW720.005900
(CW720.006000)
Dust cover for coupling sleeve SVK
e.g. for Fendt
CW720.007900
Dust cover for coupling plug flat
e.g. for Holder
CW720.005200
6
Straight screw socket
1
CW730.008600
7
Straight screw socket
2
CW730.008800
8
Mounting bar for flow divider
complete items no. 8.1 – 8.5
1
CB856.085000
8.1
Fastening section
1
CA856.085100
8.2
Support section
1
CB856.085200
8.3
Hexagon head screw
1
093312020
8.4
Hexagon head screw
2
093106090
8.5
Hexagon nut
2
098506
9
Cable tie
not shown
3
CW830.063300
Note:
Item no. 8 Mounting bar for flow divider may differ depending on the mounting frame used:
For HEXAGON frames we use the Mounting bar CC856.085000
For TERACTIV frames, an additional CL860.010009 clamping strap and two screw-on sets
093112110 + 098512 + 012315 are required. The order number of the complete group item no.
8 + additional parts is CE856.085000.
For SB frames, the fastening section pos. 8.1 is welded to the frame.
