Clemens Technologies RADIUS SL PLUS User Manual

RADIUS SL PLUS 03.2019 en 73
Item no.
Specification
Remark
Quantity
Order no.
Override valve electric 1-sided
complete items 1 - 14 + hoses
CF856.097000
1
Fastening section
1
CA856.085100
2
Slide section
1
CA895.359100
3.1
Valve housing
incl. expander
1
CA895.391101
3.2
Electrovalve 4/2 ways
1
CW760.010900
4
Electric parts complete 1 sided
complete incl. items 4.1 - 4.8
CI895.391300
4.1
Housing
1
CI895.391310
4.2
Magnetic clamp, white with hook
1
CW500.010200
4.3
Toggle switch
1
CW820.027900
4.4
Signal light LED
1
CW820.028000
4.5
Cable
1500 mm (59.1“)
1
CW830.000100
4.6
Cable fitting
2
CW830.033900
4.7
Plug 3-pin
1
CW830.044200
4.8
Valve connector
incl. cable 4000 mm (157.5”)
1
CW830.099900
5
Hydraulic hose 2000 mm (78.7“)
1
CW700.038800
6
Hydraulikschlauch 1700 mm (66.9“)
1
CW700.023900
7
Coupling plug
1
CW720.000200
8
Dust cover
2
CW720.005900
9
Straight screw socket
6
CW730.008800
10
Cable tie, black
not shown
3
CW830.063300
11
Hexagon head screw
2
093106070
12
Hexagon head screw
1
093312020
13
Hexagon nut
2
098506
14
Washer
4
144006
15
Coupling plug
1
CW720.001000
A = Return oil hose RADIUS
Item no.
Specification
Remark
Quantity
Order no.
1
Hydraulic hose 2000 mm (78.7”)
„L“ = length in mm
1
CW700.001700
2
Threaded hose stem
1
CW011.620800
3
Clip, 1 eye
2
CW500.034100
B = Return oil hose
Item no.
Specification
Remark
Quantity
Order no.
1
Hydraulikschlauch 3000 mm (118.1“)
„L“ = length in mm
1
CW700.002100
2
Threaded hose stem
1
CW011.620100
3
Threaded hose stem
1
CW011.620900
4
Clip, 1 eye
2
CW500.034000
“L“ = length in mm incl. pressed fittings
“L“ = length in mm incl. pressed fittings
2
3
1
3
1
3
2
4
4
