ClimateWorx M52 - Historical Event Log

Advanced M52 Microprocessor User's Guide
ADVANCED M52UMCT2019 COLOR
24
Low pressure Comp. 2
EXP 2
N
on Critical
Overload Comp. 2
EXP 2
N
on Critical
High R. Temp R. Sensor
N
on Critical
Low R. Temp R. Sensor
N
on Critical
High R. Humidity R. Sensor
N
on Critical
Low R. Humidity R. Sensor
N
on Critical
Loss of R. Sensor R. Sensor Critical
High S. Temp S. Sensor
N
on Critical
Low S. Temp
S. Sensor Non Critical
High S. Humidity
S. Sensor Non Critical
Low S. Humidity
S. Sensor Non Critical
Loss of S. Sensor
S. Sensor Non Critical
High Voltage
Main Board Non Critical
Low Voltage Main Board Non Critical
Custom Fault 1 Main Board Non Critical
Custom Fault 2 Main Board Non Critical
Loss of EX1 EXP 1 Non Critical
Loss of EX2 EXP 1 Non Critical
F Drier dirty Filter Sensor Non Crirical
3
Note:
3
The Filter Drier Alarm set point is a fixed amount between the entering temperature and the leaving
temperature. When the difference exceeds 3°C or 5.4
°F the alarm will be activated.
