152
MODBUS registers
10.5 Password-protected unit parameters
The unit leaves the factory with the unit parameters set by default to values capable of fulfilling most instal-
lation situations. For detailed customisation of the system, however, it is possible to make changes; a list of
all the unit parameters, with the available settings, is given below.
Depending on the configuration of the unit, some parameters are visible and others are not.
W
CAUTION
Access to parameters or modifications are only allowed to a qualified serviceman who assumes all respon-
sibility, in case of doubt contact Clivet. For any changes not permitted or not approved by Clivet, Clivet
declines any responsibility for malfunctions and/or damage to the unit/system and to people
Address
register
Meaning Description
200 Type of Unit reserved, factory data
201
T1S Upper
temperature limit set
in cooling mode
The 8 low bits represent zone 1 and the 8 high bits represent zone 2
The 8 low bits represent area 1 and the 8 high bits represent area 2
202
T1S Lower
temperature limit set
in cooling mode
The 8 low bits represent zone 1 and the 8 high bits represent zone 2
The 8 low bits represent area 1 and the 8 high bits represent area 2
203
T1S Upper
temperature limit set
in heating mode
The 8 low bits represent zone 1 and the 8 high bits represent zone 2
The 8 low bits represent area 1 and the 8 high bits represent area 2
204
T1S Lower
temperature limit set
in heating mode
The 8 low bits represent zone 1 and the 8 high bits represent zone 2
The 8 low bits represent area 1 and the 8 high bits represent area 2
205
TS Set the upper
temperature limit
Reading = actual*2 actual value *2
206
TS Set the lower
temperature limit
Reading = actual*2 actual value *2
207
DHW upper
temperature limit
208
DHW lower
temperature limit
209
Recirculation pump
operating time
Recirculation pump, default operating time 5 minutes, adjustment range
5 - 120 min, with steps of 1 min
Installer
