MODBUS registers

Address

Meaning Description

210 Parameter setting 1

BIT15 DHW enabling/disabling

BIT14 Storage tank water electric heater TBH (read only)

BIT13 Disinfect function

BIT12 DHW pump; 1=enabled ; 0=disabled

BIT11 Reserved

BIT10 The DHW pump supports pipe disinfection

BIT9 Cooling mode enabling

BIT8

T1S cooling mode high/low temperature control (read only)

zone 1

BIT7 Heating mode enabling

BIT6

T1S heating mode high/low temperature control (read only)

zone 1

BIT5 Backup PUMPI silent pump function, 1:backup

BIT4 Backup room temperature sensor Ta

BIT3 Room thermostat (Room thermostat)

BIT2 Room thermostat - MODE SETTING

BIT1 Double room thermostat, 1=enabled; 0=disabled

BIT0

0: Room cooling and heating priority;

1: Hot water priority

210 Parameter setting 2

BIT15 DHW (double DHW double enabling) 1: Yes 0: No

BIT14 DHW control M1M2 potential-free contact 1: Yes 0: No

BIT13 RT_Ta_PCNEn (Enable small temperature board)

BIT12 Sensor Tbt2 enabling 1: Yes 0: No

BIT11 Selection of pipe length 1:> 10 m 0: <10 m

BIT10 Solar input port 1: CN18 0: CN11

BIT9 Solar module 1: Yes 0: No

BIT8

Deﬁnition of the input port:

0= remote switch

1= DHW heater

BIT7

Smart grid:

0= None

1= Yes

BIT6

T1B Sensor enabling

0= None

1= Yes

BIT5 T1S High/low cooling temp. setting zone 2

BIT4 T1S High/low heating temp. setting zone 2

BIT3 Double zone setting is eective

BIT2 Ta Sensor position 1: IDU 0: HMI

BIT1 Tbt Sensor enabling 1: Yes 0: No

BIT0 IBH / AHS Installation position 1: storage tank 0: piping

212 dT5_On

A Series: Default: 10°C range: 1 ~ 30°C

E series: Default: 5°C, range: 2 ~ 0°C control range 1°C

213 dT1S5 Default: 10°C, range: 5-40°C, Control range 1°C

214 T_Interval_DHW Default: 5min, interval: 5~5min, Control interval 1min

215 T4DHWmax Default: 43°C, range: 35-43°C, Control range 1°C

216 T4DHWmin

A Series: Default: -10°C range: -25 ~ 30°C

E series: Default: -10°C, range: -25-5°C control range 1°C

217 t_TBH_delay Default: 30min interval: 0~240min, Control interval 5min

218 dT5S_TBH_o Default: 5°C, range: 0~10°C, Control range 1°C

219 T4_TBH_on

A Series: Default: 5°C range: -5 ~ 50°C

E series: Default: 5°C, range: 5 ~ 20°C control range 1°C

Brand	CLIVET
Model	WiSAN-YME 1 S 4.1
Category	Heat Pump
Language	English
