1.4.1 Product Appearance
Power Receptor
Adapter, Input:90-240Vac, Output: 5V/ 1.2A
Reset Button
Press “Reset” button over 10 seconds. When status indicator turns from
flashing to solid, the process is completed. All settings are back to default.
Ethernet Port
1x WAN port, 4x LAN ports
USB2.0 Ports
1 USB Ports
1.4.2 Hardware Specifications
The following table shows the technical specifications of the wireless router.
Item Specifications
Communication Interface
WAN Port 1 x 10/100Mbps RJ-45, with auto MDI/MDIX
LAN Port 4 x 10/100Mbps RJ-45, with auto MDI/MDIX
Wireless IEEE 802.11b/g/n
Others
Operation
Requirement
Operating Temp: 0° to 40°C (32° to 10°F)
Storage Temp: -20° to 70°C (-4° to 158°F)
Operating Humidity: 10% to 85% Non-Condensing
Storage Humidity: 5% to 90% Non-Condensing
Sessions 20,000
