Antenna Internal x 1, External x 1 (detachable)
Peak Gain of the
antenna
2dBi@ 2.45GHz
Transmitted Power IEEE 802.11b: 19dBm +/- 2.0dBm (typical)
IEEE 802.11g: 16dBm +/- 2.0dBm (typical)
IEEE 802.11n: 14dBm +/- 1.5dBm (typical)
Receive Sensitivity
IEEE 802.11g: -70dBm +/- 2.0dBm
IEEE 802.11n (20MHz): -74dBm +/- 2.0dBm
IEEE 802.11n (20MHz): -74dBm +/- 2.0dBm
Dimension (L x W x H) 150 x 150 x 33mm (5.91 x 5.91 x 12.99inch)
Button Reboot / Reset button
WPS button
Power Supply Adapt AC 100 ~ 240V / DC 5V, 1.5A output
Certification CE / FCC / RoHS
Chapter 2 System and Network Setup
The CBR-980 is an easy to setup and wireless device for various application and environment. It can
be used in conference room, hotel, even in transportation. The USB port could connect with USB
WiMAX / 3.5G dongle.
2.1 Build Network Connection
Administrator can manage the settings for WAN, LAN, Wireless Network, NTP, password, User
Accounts, Firewall, QoS, etc.
