Appendix A: Technical specifications
98-140012-H Interfaces specifications 136
Interfaces specifications
Power input
Connector pin-out
This drawing shows the pin-out for the DC Power connector.
Specifications
AC/DC adapter
External battery connector
The external battery connector is a custom connector strictly for connecting a Cobham SAT-
COM EXPLORER 710 battery with a dedicated EXPLORER 710 Hot Swap Cable (part number
403720B-010).
Item Specification
DC input range +10 to +32 VDC
Power consumption up to 65 W depending on usage
Connector type Power Jack - 2,5 mm Center
Item Specification
AC input range 100 to 240 VAC, 1.5 A, 47 to 63 Hz
DC output 19 VDC, 65 W
