Chapter 4: To use the web interface
98-140012-H To set up the interfaces 63
To set up the interfaces
LAN interface setup
The terminal has two LAN connectors. LAN#1 is with PoE (Power over Ethernet).
To configure the LAN interface, do as follows:
1. In the Control panel
, click the LAN icon at the top of the page.
2. To enable the LAN interface, select Enable.
3. To enable Power over Ethernet (PoE) on LAN#1, select Enable next to Power over
Ethernet. PoE is used e.g. for powering IP handsets. If you are not using PoE, you can save
power by disabling PoE.
4. Click Save.
• A line through a grayed-out LAN icon means the interface is disabled.
• A blue LAN icon means the interface is enabled.
For a description of how to set up the local network parameters, see Internet and LAN
connection modes on page 75 and Advanced LAN on page 90.
WLAN interface setup
To configure the WLAN interface, do as follows:
1. In the Control panel
, click the WLAN icon at the top of the page.
2. To enable the WLAN interface, select Enable.
3. Next to Region, select the region you are located in.
4. Select the Channel number used for communication on the WLAN interface.
5. Select Broadcast SSID to show your WLAN access point to other users.
If you clear the box, your WLAN access point is hidden.
6. Type in the SSID.
The SSID is a max. 32 character text identifying the wireless local area network. All wireless
devices on a WLAN must use the same SSID in order to communicate with each other. The
default SSID is EXPLORER710.
7. Select the Security standard. You may select one of the following encryption standards:
It may take some seconds to enable the interface.
The Internet settings entered in the Terminal settings page also apply for the WLAN
interface. See Internet and LAN connection modes on page 75.
It may take some seconds to enable the interface.
In some countries, the use of WLAN is not allowed. Before continuing, make sure
WLAN is allowed and licensed in the country where you intend to use it.
