Appendix A: Technical specifications
98-140012-H Interfaces specifications 140
WLAN access point
Specifications
USB (Host) interface
Connector pin-out
Specifications
Item Specification
Standard IEEE 802.11 b/g
Antenna External rotatable antenna for increased coverage
Frequencies 2.4 GHz ISM band
Max. coverage outdoor 100 m / 328 ft
Pin Function
1VBUS
2D-
3D+
4GND
Item Specification
Version USB v2.0 Host
Connector type Type A
Charge current available 0.5 A or 2.0 A, user selectable
Max. cable length 5 m / 16.4 ft
