2.3.4 Grounding
WARNING!!! Do not use the repeater grounding bolt to connect external devices.
To ground the repeater
• Refer to the grounding requirements described in section 2.2.2.
• Connect the grounding protection to the repeaters ground lug.
Figure
2-15: Grounding the MBF-40
