MBF-40 SMR700/SMR800 PS REPEATER
PRODUCT DESCRIPTION AND USER’S MANUAL
Cobham Wireless – Coverage Date: 28-Jan-16 www.cobham.com/wireless
Doc. No. 00046UM Rev. 2.1
Page | 33
3 GETTING STARTED
This chapter includes the following information:
• Opening a repeater session
• Navigating the WEB GUI
• Initial setup procedure
3.1 Opening a Repeater Session
Two types of session can be opened to the repeater:
• Direct session – this is usually a direct local session to the repeater
• Remote session – this is usually done by opening a session to the OMU II and then connecting to
the repeater (via the OMU II)
3.1.1 Opening a Direct Local Session
NOTE: This connection requires downloading the USB driver from the provided setup disk (or connection to the
internet, where the driver is automatically loaded).
To open a local session:
1. Open the MBF-40 cover
• Connect to the USB port on the Controller module. If the USB driver is not already installed
on your laptop, the system will search for the driver on the provided setup disk or on the
internet (if a network connection is available).
• Run a browser and login according to the following section.
Figure 3-1: MBF-40 Controller Module Connection
1. Open the web browser and type
"axell-ne"
in the address bar.
USB cable
