MBF-40 SMR700/SMR800 PS REPEATER
PRODUCT DESCRIPTION AND USER’S MANUAL
www.cobham.com/wireless Date: 28-Jan-16 Cobham Wireless – Coverage
Page | 56
Rev. 2.1 Doc. No. 00046UM
5.1.1 General Page Area
Figure 5-2: MBF-40 General
Indicator Description
Temperature Current ambient temperature
Tag Name of Repeater, user customizable
Door Status Green if closed
Received Data Quality Check data for consistencies
5.1.2 Detailed view of the MBF-40
Figure 5-3: MBF-40 Repeater Status
