Chapter 2: Installation
2-7
Installation
98-131571-B
4 Removeallkey-holescrewsfromtheback.
5 Usingahacksaw,cutawaythebackpart,ofthebottomplate,byfollowingthepre-cutlines.
Dothisonsections,whereconnectionboardsaretted.
6 Mountallkey-holescrews,fromtheinsideoftheconsole.
Mountingtheconsoleontothebulkhead
6
4
9
