COBHAM Satcom SAILOR XTR GX-R2 User Manual

98-175666-D Appendix F: Event messages F-6
List of events
08521-0 ADM ERROR Azi axis
calibration
Azimuth axis zero reference not found.
Check belt and zero reference module.
Info: 0x00000001: Timeout (operation did
not complete in time) 0x00000010:
Encoder or mechanical problem
0x00000020: Zero reference not found
0x00000040: End stop not found.
08522-0 ADM ERROR Xel axis
calibration
Cross-elevation axis zero reference or end
stops not found at expected locations.
Check belt, zero reference module, and
end stops. Info: See 08521-0.
08523-0 ADM ERROR Ele axis
calibration
Elevation axis zero reference or end stops
not found at expected locations. Check
belt, zero reference module, and end
stops. Info: See 08521-0.
08524-0 ADM ERROR Pol axis
calibration
Polarisation axis zero reference or end
stops not found at expected locations.
Check movement of the polarisation unit
and the zero reference module. Info: See
08521-0.
08525-0 ADM ERROR Antenna
calibration
One or more errors occurred during
antenna start-up Info: 0x00000001:
Timeout (calibration did not complete in
time) 0x00000010: Azimuth axis
0x00000020: Cross-elevation axis
0x00000040: Elevation axis
0x00000080: Polarisation axis
08534-0 ADM WARNING ACU
communication
The communication link between BDU
and antenna is not working.
08537-0 ADM INFO GNSS
communication
Lost connection to the GNSS device.
08538-0 ADM INFO GNSS data
range
Received information from the GNSS
device which is out of range.
08539-0 ADM WARNING GNSS device
warning
Local GNSS device warning.
0853A-0 ADM WARNING GNSS device
error
Local GNSS device error.
0853B-0 ADM WARNING GNSS Fallback Position mode fallback to local GNSS,
caused by missing NMEA messages.
ID Module Type Description Explanation
Table F-1: Event messages (Continued)
