COBHAM Satcom SAILOR XTR GX-R2 User Manual

SAILOR XTR GX-R2 system
98-175666-D Chapter 1: Introduction 1-7
6. Azimuth Zero Reference Module.
7. Rotary joint. (not visible in photo).
8. Feed horn.
9. XTR Antenna Control Module (ACM).
10. ADU power on/off.
11. GNSS module (GPS, GLONASS, BEIDOU).
Figure 1-6: SAILOR 600 XTR GX-R2: ADU modules 2/2
8
6
7
9
10
8
