SAILOR XTR GX-R2 system
98-175666-D Chapter 1: Introduction 1-6
Modules in the ADU (SAILOR 600 XTR GX-R2)
1. Cross elevation motor.
2. Elevation motor.
3. GX-R2 Ka-band transceiver.
4. Inertial Sensor Module (ISM).
5. Azimuth Motor.
Figure 1-5: SAILOR 600 XTR GX-R2)ADU modules 1/2
3
4
2
1
5
