COBHAM Satcom SAILOR XTR GX-R2 User Manual

98-175666-D v
Safety summary
The following general safety precautions must be observed during all phases of operation,
service and repair of this equipment. Failure to comply with these precautions or with
specific warnings elsewhere in this manual violates safety standards of design,
manufacture and intended use of the equipment. Thrane & Thrane A/S assumes no
liability for the customer's failure to comply with these requirements.
Microwave radiation hazards
During transmission the Above Deck Unit (antenna) in this system radiates Microwave
Power.This radiation may be hazardous to humans close to the Above Deck Unit. During
transmission, make sure that nobody gets closer than the recommended minimum safety
distance.
SAILOR 1000 XTR GX-R2
The minimum safety distance to
the antenna reflector on the focal
line is 30 m for SAILOR 1000 XTR
GX-R2 4.5W, and 55 m for
SAILOR 1000 XTR GX-R2 9W, based
on a radiation level of 10 W/m
2
. No
hazard exists >18° below the
antenna’s mounting plane. Refer to
the drawing below.
MICROWAVE RADIATION

COBHAM Satcom SAILOR XTR GX-R2 Specifications

General

Brand	COBHAM
Model	Satcom SAILOR XTR GX-R2
Category	Marine Equipment
Language	English
